Descrizione
Access Control List (ACL)
Auto MDI / MDI-X
Tecnologia di cablaggio in rame ethernet. 10BASE-T, 100BASE-TX
Intervallo di temperatura di funzionamento. 0 - 40 ° C
Collega e usa
Impilabile
Specifiche tecniche
| Network standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
|---|---|
| LED Indicator | 1* Power,16* Link/Act |
| Interfaces | 16*10/100 Base-TX Ethernet ports (Auto MDI/MDIX) |
| Transmission media | Recommended: CAT5/5e UTP or better |
| Fan quantity | N/A |
| Dimension | 294.0mmx180.0mmx44.0mm |
| Material | Metal |
| Level of protection | Lightning protection for ports: N/A Lightning protection for power: 6KV ESD: Air discharge: ±10kV Contact discharge: ±8kV |
| Forwarding mode | Store-and-forward |
| Switch capacity | 3.2Gbps |
| Packet forwarding rate | 2.38Mpps |
| Buffer | 1.25Mb |
| MAC address table | 4K |
| Jombo frame | N/A |
| Power | Input: 100-240V AC 50/60Hz |
| Power consumption | Max: 6W |
| Mounting | Desktop mounting: support Wall mounting: support Rack mounting : support |
| Environment | Operating temperature: 0°C - 45? Storage temperature: -40°C - 70°C Operating humidity: (10% - 90%) RH, non-condensing Storage humidity: (5% - 90%) RH, non-condensing |
| Certification | CE, FCC, RoHS |
| Protocols | CDMA/CD |
| MAC address learning | Auto-Learning and Auto-Aging |
| Funtions | plug-and-play |
